DLAB OS20-S Overhead Stirrer

$780.00

Available: In Stock

DLAB produces some of the best overhead stirrers on the market. The OS20-S is an excellent combination of safety, features and efficiency. A great buy for any laboratory, this stirrer is up to the task for demanding tasks like chemical synthesis, pharmaceutical synthesis, chemical analysis.

Buy Accessories

Features:

  • Reliable overhead stirrer
  • Excellent level of performance
  • Extensive speed range, that can be adjusted from 50 to 2200 rpm
  • Virtually maintenance free and explosion proof brushless DC motor
  • Get accurate speed readings from the OS20-S’ LED screen
  • Special safety circuits provide reliable stop functionality in case of anti-stall or overload problems

Product Specs

Max. stirring quantity(H2O) 20L
Motor type brushless DC motor
Motor input power 60W
Motor output power 50W
Voltage 100-220V, 50/60 Hz
Power 70W
Speed range 50-2200rpm
Speed display accuracy ±3rpm
Speed display LED
Overload protection display LED lights
Max. torque 40Ncm
Viscosity max. 10000mPas
Chuck range diameter 0.5-10mm
Dimension[WxHxD] 83x220x186mm
Weight 2.8kg
Protection class IP42
Permissible ambient temperature and humidity 5-40°C, 80%RH

Product Package

Cat. No. P/N Descriptions Power supply
8033100200 OS20-S LED Digital Overhead Stirrer , Max. stirring quantity 20L USA plug,100V-220V/50Hz/60Hz
Cn plug,100V-220V/50Hz/60Hz
Euro plug,100V-220V/50Hz/60Hz
UK plug,100V-220V/50Hz/60Hz
OS20-S main body 8033100200 +Universal plate stand18900258 +Crossed stirrer18900071 OS20-S package4

Accessories

Cat. No. Descriptions
18900258 Universal plate stand(WxD: 20x31cm), including support holder(H: 78cm) and fixing device Grey
18900131 Universal plate stand(WxD: 20x31cm), including support holder(H: 78cm) and fixing device
18900071 Crossed stirrer, shaft length 40cm,stirrer diameter 5cm, 316L stainless steel
18900072 Straight stirrer, shaft length 40cm,stirrer diameter 6cm, 316L stainless steel
18900073 Blade stirrer, shaft length 40cm,stirrer diameter 6.8cm, 316L stainless steel
18900074 Centrifugal stirrer, shaft length 40cm,stirrer diameter 9cm, 316L stainless steel
18900075 Crossed stirrer, shaft length 35cm,stirrer diameter 6.5cm, PTFE coated
18900076 Straight stirrer, shaft length 35cm,stirrer diameter 7cm, PTFE coated
18900077 Blade stirrer, shaft length 35cm,stirrer diameter 6.8cm, PTFE coated
18900078 Centrifugal stirrer, shaft length 35cm,stirrer diameter 8.5cm, PTFE coated
18900330 Crossed stirrer, shaft length 40cm,stirrer diameter 5cm, 316L stainless steel (prevent the liquid spills)
