- DLAB MS-H-S Magnetic Hot Plate Stirrer
$490.00
Available: In Stock
For laboratories that need safe and reliable magnetic hot plate stirrers, at a great price, the MS-H-S from DLAB offers a solution. Capable and efficient it can be utilized in chemical synthesis, physical and chemical analysis, bio-pharmaceuticals.
Enquiry about DLAB MS-H-S Magnetic Hot Plate Stirrer
Features:
- Accurate stir control up to 1500rpm
- Operate the stirrer at temps up to 340°C
- H2O maximum stir quantity – 20 liters
- Easy to read LCD display with accurate temperature and speed readings
- Control the temperature externally by connecting the PT1000 sensor and get regains at ±0.2°C accuracy
- Take advantage of remote functionality allowing for PC control and data transfer
- Very high quality magnetic hot plate stirrer, with a stainless-steel work plate, covered with ceramic for increased chemical resistance
- Special accessories available
- Safety features like blinking “HOT” warning for temps over 50°C and overheating protection
Product Specs
| Specifications | MS-H-S |
| Work plate dimension | φ135mm(5 inch) |
| Work plate material | stainless steel cover with ceramic |
| Motor type | Brushless DC motor |
| Motor rating input | 18W |
| Motor rating output | 10W |
| Power | 550W |
| Heating output | 500W |
| Voltage | 100-120/200-240V 50/60Hz |
| Stirring positions | 1 |
| Max. stirring quantity[H2O] | 20L |
| Max. magnetic bar[length] | 80mm |
| Speed range | 100-1500rpm resolution±1rpm |
| Speed display | Scale |
| Temperature display | Scale |
| Heating temperature range | Room temp.-340°C |
| Over temperature protection | 350°C |
| Temperature display accuracy | ±0.5°C |
| Protection class | IP42 |
| Dimension[WxDxH] | 160×280×85mm |
| Weight | 2.8kg |
| Permissible ambient temperature and humidity | 5-40°C, 80%RH |
Accessories
| Cat. No. | P/N | Descriptions | Power supply |
| 8030211010 | MS-H-S | Classic Hotplate Magnetic Stirrer，stainless steel with ceramic coated hotplate，heating temperature up to 340°C | USA plug,100V-120V/50Hz/60Hz |
| Cn plug,200V-240V/50Hz/60Hz | |||
| Euro plug,200V-240V/50Hz/60Hz | |||
| UK plug,200V-240V/50Hz/60Hz |
