DLAB DM0636 Multi-Purpose Clinical Centrifuge


Available: In Stock

A highly versatile multi-purpose clinical centrifuge, the DM0636. It is very suitable for handling samples in chemical labs, cytology, research facilities, industrial labs. This DLAB centrifuge can work with various tubes – with caps, blood collection or urine tubes, as well. Compatibility with typical 100mL tubes at lower speeds, of the swing-out bucket rotors and adapters.

Buy Accessories


  • Extensive speed range – adjust from 300 to 6000rpm
  • The DM0636’s maximum capacity is 100 mLx4
  • Highly efficient separation is guaranteed by the 9 acceleration and 10 break speed settings
  • This multi-purpose clinical centrifuge is compatible is an array of additional accessories
  • Automatic rotor identification
  • Flexible time settings – short or continuous run, up to 99 minutes
  • The operator can save up to 9 procedures in the centrifuge’s memory
  • Unit comers with virtually maintenance free brushless DC motors

Product Specs

Speed range 300-6000rpm
Max. RCF 4300xg
Speed accuracy ±20rpm
Max. Capacity 100mLx4
Run Time 30sec-99mins/continuous
Motor Brushless DC
Display LCD
Program Memory 9
Safety Devices Door Imbalance protection
Over speed & Over temperature detection
Acceleration/Deceleration time 9↑/10↓
Power 660W; Single-phase AC220V-240V, 50Hz/60Hz, 6.3A; AC110V-120V,50Hz/60Hz,10A
Dimension[WxDxH] 445x579x269mm
Weight 36kg
Certification CE cTÜVus FCC IVD
Advanced features speed/rcf switch;
Rotor identification


Cat. No. P/N Descriptions Power supply
9015001123 DM0636 Multi-Purpose Clinical Centrifuge(standard package),with swing-out rotor kit19400041 & 100ml basket 19400042(select them below) US plug, 110-120V/50Hz/60Hz
Cn plug, 220-240V/50Hz/60Hz
Euro plug, 220-240V/50Hz/60Hz
UK plug, 220-240V/50Hz/60Hz
DM0636 main body+ A30-15 rotor 19400040 DM0636 package1
DM0636 main body+ A8-50 rotor 19400039 DM0636 package2
DM0636 main body+SE4-100 rotor19400041+3-10ml basket 19400045 DM0636 package3
DM0636 main body+SE4-100 rotor19400041+10-15ml basket 19400044 DM0636 package4


Cat. No. P/N Descriptions
19400041 SE4-100 Swing-out rotor with four baskets
19400045 3-10ml basket with adaptor
19400044 10-15ml basket with adaptor
19400043 50ml basket with adaptor
19400042 100ml basket with adaptor
19400040 A30-15 fix angle rotor
19400038 AS6-50V fix angle rotor for 50ml×6
19400036 AS12-PCR8 fix angle rotor PCR 8 Trips ×12
19400034 AS30-2 fix angle rotor 2ml × 30
19400037 AS60-2 fix angle rotor 2ml × 60
19400035 AS18-5V fix angle rotor 5ml ×18
19400039 A8-50 fix angle rotor 50ml × 8/15ml ×16
19400062 S2-MP Micro-plate rotor
